Rosemount-K-0085 Pipe Clamp Sensor and 3144S Transmitter

Rosemount™ 0085 Pipe Clamp Sensor and 3144S Temperature Transmitter

仕様

Rosemount™ 0085 パイプクランプ温度センサ
パイプクランプの材質
ASTM 316 SST (1.4401)、ASTM 304 SST(1.4301)、デュプレックス F51(1.4462)、炭素鋼(1.0037)
リード線
PTFE 絶縁、銀めっき銅線
絶縁抵抗
室温、DC 500 V で測定時、最小絶縁抵抗は 1,000 MΩ
校正オプション
ASTM 304 SST(1.4301)、デュプレックス F51(1.4462)、炭素鋼(1.0037)
認証/承認
危険場所、認証の完全なリストについては、詳細仕様を参照してください
Rosemount™ 3144S Temperature Transmitter
Input
Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
Output Signal
4-20 mA/HART® protocol
Housing
Dual-compartment field mount
Display/Interface
Large Graphical Backlit LCD display with Quick Service Buttons, multiple lines and percent range graph
Accuracy
± 0.05 °C reference accuracy
Stability
± 0.25 °C for 20 years (Ultra Performance), or 10 years (Classic Performance)
Diagnostics
Basic diagnostics, Loop Integrity, RTD Measurement Protection, Hot Backup™ capability, Sensor Drift Alert, Thermocouple Degradation, Configurable Process Alerts
Calibration Options
Transmitter-Sensor Matching (Callendar-Van Dusen constants)
Certifications/Approvals
SIL2 certified and SIL3 capable to IEC 61508 by an independent 3rd party, hazardous location, marine type, see Quick Start Guide for complete list of certifications

機能

Rosemount™ 0085 パイプクランプ温度センサ
  • センサは -50~+300°C(-58~+572°F)と広い温度範囲をカバーするので、アプリケーションの要件を満たします
  • Rosemount 648 ワイヤレス温度伝送器に直接取付けることで Rosemount X-well™ テクノロジによる高精度の温度計測ができます
  • 幅広いクランプの様式、サイズ、材質により、どこでも設置が可能で、様々な用途に柔軟に適応します
  • パイプの切断や溶接を必要としない簡単な設置
  • プラチナ RTD 温度センサは、応答時間を改善するため、銀製チップ使用の設計です
  • 高速、重液、微粒子などのアプリケーションにも耐えうる耐久性と安定性があります。
  • 非挿入設計のため毒性のある流体へのプロセス侵入が不要になり、安全性が向上します。
  • スプリング式センサで表面との接触を最適化し、測定性能を高めています
Rosemount™ 3144S Temperature Transmitter
  • Industry-leading accuracy and reliability for best performance in critical control and safety applications
  • 20-year long-term stability extends calibration intervals to reduce trips to the field
  • 20-year limited warranty provides assurance and peace of mind that comes with purchasing a Rosemount product
  • ReadyConnect™ Technology provides plug-and-play sensor configuration to help you save time and eliminate errors
  • Rosemount X-well Technology measures temperatures up to 650°C (1202°F) without a process penetration for reduced design, installation and maintenance costs
  • RTD Measurement Protection converts your configuration from a 4-wire to a 3-wire configuration if a wire is broken or damaged, helping to avoid loss of measurement and downtime
  • Bluetooth® Connectivity helps you work easier, safer, and more efficiently with simplified operator rounds, a consistent application experience across Emerson devices, and by avoiding the need for a hot work permit
  • Loop Integrity diagnostic continuously monitors the health of the entire electrical loop to detect potential failures before they happen
  • Hot Backup™ capability and Sensor Drift Alert utilizing dual sensors ensure measurement integrity
  • Thermocouple Degradation diagnostic monitors thermocouple health to detect degradation before failure
  • Guided Proof Testing provides an easy, step-by-step process to help ensure you are operating safely and properly
  • Dual-compartment housing provides superior protection in harsh environments
