Rosemount-Synchros Temperature Monitor

Rosemount™ Synchros™ Temperature Monitor

製品概要

Unlock new asset monitoring and reliability temperature measurement points and gain more visibility into the health of your assets with the Rosemount Synchros Temperature Monitor. This easy-to-use wireless temperature monitoring device reliably measures surface or ambient temperature using your new or existing WirelessHART® network. Increase your temperature measurement data and insights with this simple, flexible, and cost-effective solution, allowing you to schedule maintenance more proactively and reduce your manual rounds, resulting in a safer, more reliable, and optimized operations.

Communication Protocol
WirelessHART®
Reference Accuracy
Surface Measurements: ± 1.8°F (1.0°C)
Ambient Measurements: ± 2.7°F (1.5°C)
Measurement Range
Surface Measurements: -40 to 230°F (-40 to 110°C)
Ambient Measurements: -40 to 185°F (-40 to 85°C)
Operating Temperature
-40 to 212 °F (-40 to 100 °C)
Mounting
Bracket and Pipe Mount
Update Rate
Up to 1 min. (5 min. default), user selectable
Power Module Life
Up to 10-year life, field replaceable
Antenna Type
Internal antenna: Maximum of 10mW (10 dBm) EIRP
Certifications/Approvals
Hazardous location rated, see full specs for complete list of certifications

機能

  • Measures ambient or surface temperature in a variety of applications
  • Directly mounts to process piping without cutting or changing pipe configurations to measure surface temperature, allowing for flexible, simple installation
  • Install easily and quickly to bracket mounting hardware to enable ambient temperature monitoring
  • Utilize WirelessHART technology for secure, cost-effective and greater than 99% data reliability
  • Integrates with Emerson’s Plantweb Insight™ Asset View application to help manage your Synchros devices and configure asset specific alerts
